Specifications
| Working Diameter | 400 mm or 600 mm or 800 mm |
| DOF | 3-axis or 4-axis or 5-axis or 6-axis |
| Conveyor X | None or L1200 D200 or L1200 D300 |
| Aluminum Frame | None or 4080 Aluminum Frame |
| Accuracy | 0.2 mm |
| Max Payload | 2 kg |
| Mass | 30 kg |
| Max Speed | 3 m/s |
| Max Acceleration | 50 m/s2 |
| Communication | USB/RS232/RS485/Ethernet |
| Input | 2 Analog Input / 4 Digital Input |
| Output | 8 Digital Output |
| Max Pick Rate | 90 picks/min |
| Operating environment | Industry |
| Repetition Accuracy | +-0.1mm |
| Industrial Camera | Basler a2A1920-160ucBAS (1920x1200 pixel, 160 fps, global shutter, color cam) |
| Camera Lighting | LED-4090 (80k LUX, 90mm Outside Dia, 40mm Inside Dia, 22mm Thickness) |
| Camera Connection | USB3.0 |
| X Encoder Kit | Encoder (1024 pul/rev, 5-24VDC, NPN output) |
| Calibration Camera | USB Camera (1920x1080, 30fps) |
| Vaccum Kit | Vaccum Kit |
